Function Setting Table
205
Function Setting details Setting Default Referent
F−60 Setting of INPUT1
operation
00 (Off),
01 (Zero set),
02 (Zero set clear),
03 (Hold (level)),
04 (Hold (pulse)),
05 (PEAK/TRACK),
06 (RESET),
07 (SEL1),
08 (SEL2),
09 (CHECK value),
10 (Comprehensive key lock),
11 (Print command (only when
the serial interface card is
mounted)),
12 (Forced termination of
multimode)
00 (Off) 8.1 External control
input signal
F−61 Setting of INPUT2 Ditto 00 (Off) 8.1 External control
input signal
F−62 Setting of INPUT3 Ditto 00 (Off) 8.1 External control
input signal
F−63 Setting of INPUT4 Ditto 00 (Off) 8.1 External control
input signal
F−64 Setting of INPUT5 Ditto 00 (Off) 8.1 External control
input signal
F−65 Setting of INPUT6 Ditto 00 (Off) 8.1 External control
input signal
F−69 INPUT signal
response time
0 (50 ms), 1 (20 ms),
2 (10 ms), 3 (5 ms),
4 (2 ms), 5 (1 ms)
0 (50 ms) 8.1 External control
input signal
F−70 Setting of
OUTPUT1
operation
00 (Off),
01 (Hold),
02 ([PEAK] LED is on),
03 ([MEAS.) LED is on),
04 ([END] LED is on),
05 (Multimode),
06
(Measurement in multimode),
07 (Results of waveform
comparison and detection
result judgment are
acceptable),
08 (Results of waveform
comparison and detection
result judgment are
unacceptable),
09
(Result of detection result
judgment exceeds upper limit),
10 (Open collector S0 is
turned on in comparator),
11 (Open collector S1 is
turned on in comparator),
12 (Open collector S2 is
turned on in comparator),
13 (Occurrence of error),
14 (Occurrence of overload),
15 (Executing zero set),
16 (Executing process (level)),
17 (Executing process (pulse))
00 (Off) 8.2 External control
output signal
To Next Page
