A Specifications of CSD-709
137
A.7 USB Interface (for connection with EzCTS and specialized application)
Specifications Compatible with USB2.0 (can also be used with USB1.1 compatible
equipment)
Output connector B type mini-USB connector
CAUTION
To use the USB interface, you must install the specialized driver to the PC used as
host.
A.8 General Specifications
Operating
temperature/humidity
range
Temperature
-10°C ~ 50°C
Humidity 85 %RH, max (No condensation is permitted.)
Stored
temperature
-20°C ~ 60°C
Power supply
Power supply
voltage
100 VAC ~ 240 VAC (Allowable fluctuation range:
85 VAC ~ 264 VAC)
Power supply
frequency
50/60 Hz
Power
consumption
Approx. 10 VA (@ 100 VAC; no option)
Approx. 18 VA, max (@ 100 VAC; equipped with optional
CC-Link)
Inrush current
AC
configuration
5 A (1 ms) in 100 VAC average load condition (ordinary
temperature and cold start)
10 A (1 ms) in 200 VAC average load condition (ordinary
temperature and cold start)
External dimensions
(W x H x D)
96 mm × 48 mm × 110 mm (excluding projections)
Weight Approx. 630 g (excluding options)
A.9 Standard Shipment Specifications
Bridge power supply 10 VDC
Span adjustment The value [30 000] is displayed at 3.0 mV/V input
Minimum scale 1
