Function Setting Table
204
Function Setting details Setting Default Referent
F−47 Communication
settings for
RS-232C and
RS-422/485
First digit: Data bit length
(0 (7 bit), 1 (8 bit)),
Second digit: Parity bit
(0 (No parity),
1 (Even parity),
2 (Odd parity)),
Third digit: Stop bit
(0 (1 bit), 1 (2 bit)),
Fourth digit: Baud rate
(0 (1 200 bps), 1 (2 400 bps),
2 (4 800 bps), 3 (9 600 bps),
4 (19 200 bps),
5 (38 400 bps),
6 (57 600 bps), and
7 (115 200 bps)),
Fifth digit: Terminator (0 (CR),
1 (CR+LF))
13020 H.3 Setting, I.3 Setting
F−48 Decimal point 0 (Hide), 1 (Add) 0 (Hide) H.3 Setting, I.3 Setting
F−49 Setting of number
of digits of unit
(combination of
load display and
status)
0 (Two digits), 1 (Three digits) 0 (Two digits) H.3 Setting, I.3 Setting
F−50 Setting of
RS-422/485 and
Modbus IDs
00 ~ 31
00 I.3 Setting
F−51 Change between
RS-422 and
RS-485
0 (RS-422), 1 (RS-485) 0 (RS-422) I.3 Setting
F−52 Return data delay
in RS-485
0 ~ 99 (unit: 10 ms)
0 ms I.3 Setting
F−55 Setting of F key
operation
0 (No assignment),
1 (Display value hold),
2 (Zero set),
3 (Zero set clear),
4 (Print command through
serial interface),
5 (Transition to COMP setting
mode),
6 (Confirmation of CC-Link
station number and
RS-422/485 ID),
7 (Forced termination of
multimode)
0 (No
assignment)
7.7 Setting the F key
operation
