Minebea CSD-709 User Manual

4 Settings Related to Measurement
53
4
Settings Related to Measurement
4.1 Overview
The CSD-709 processes the inputs from the measuring units and transforms the results into
calculated values.
The sampling frequency for AD conversion determines the reproducibility of the digital data against
the inputs.
Sampling frequency for AD conversion
Low High
Influence of noise
Less susceptible Highly susceptible
Reproducibility of noise
Low High
The digital low-pass filter and moving average determine the magnitude of influence of unexpectedly
generated noises.
Digital low-pass filter
Low frequency High frequency
Influence of noise
Less susceptible Highly susceptible
Reproducibility of noise
Low High
Moving average frequency
Low High
Influence of noise
Less susceptible Highly susceptible
Processing time
Short Long
Analog signal
Data sampling and AD conversion
Calculated value
Digital low-pass filter
(set per AD sampling frequency)
Stabilization based on moving
average
