Minebea CSD-709 User Manual

G BCD Card CSD-709-15/CSD-709-16
176
G.4 Timing chart
▼ Measurement mode
※ Output transistor turns ON (Negative logic in electrical theory) when all of the P.C., DATA and POL
output the data.
▼ When data is over (±OL display)
※Output transistor of OVR signal turns ON (Negative logic in electrical theory) while OVR is output.
Moreover, for all DATA when OVR is output, the output transistor becomes OFF status
(Positive logic in electrical theory)
▼ When the error is occurred.
※Output transistor of ERROR signal turns on (Negative logic in electrical theory) while ERROR is output.
Moreover, for all DATA and POL when ERROR is output, the output transistor becomes OFF status
(Positive logic in electrical theory).
▼ When HOLD signal is input.
※Output transistor of P.C. turns off (Positive logic in electrical theory) while HOLD signal is input.
※The response time showing above will take for HOLD or reset of DATA and POL., after HOLD signal is
input. (The input response time is set by function.)
ON
ON
DATA
POL
P.C.
OVR
ON
ON
DATA
POL
P.C.
ERROR
ON
2 000 times/s：
400 times/s：
50 times/s：
4 times/s：
A
pprox. 0.25ms at max.+Input response time,
A
pprox. 1 ms at max.+Input response time,
A
pprox. 10 ms at max.+Input response time,
A
ppro
x
. 50 ms at max.+Input response time,
HOLD
DATA
POL
P.C.
ON
ON
A
pprox. 0.25 ms at max. +Input response time
A
pprox. 2.5 ms at max.+Input response time
A
ppro
x
. 20 ms at max.+Input response time
A
ppro
x
. 250 ms at max +Input response time
4 000 times/s：
1 000 times/s：
100 times/s：
20 times/s：
A
pprox. 0.25 ms at max.+Input response time
A
pprox. 0.5 ms at max.+Input response time
A
pprox. 1 ms at max.+Input response time
A
pprox. 2.5 ms at max.+Input response time
A
pprox. 10 ms at max.+Input response time
A
ppro
x
. 20 ms at max.+Input response time
A
ppro
x
. 50 ms at max.+Input response time
A
ppro
x
.250 ms at max +Input response time
4 000 times/s：
2 000 times/s：
1 000 times/s：
400 times/s：
100 times/s：
50 times/s：
20 times/s：
4 times/s：
4 000 times/s：
2 000 times/s：
1 000 times/s：
400 times/s：
100 times/s：
50 times/s：
20 times/s：
4 times/s：
A
pprox. 0.25 ms at max. +Input response time
A
pprox. 0.5 ms at max.+Input response time
A
pprox. 1 ms at max.+Input response time
A
pprox. 2.5 ms at max.+Input response time
A
pprox. 10 ms at max. +Input response time
A
ppro
x
. 20 ms at max. +Input response time
A
ppro
x
. 50 ms at max. +Input response time
A
ppro
x
.250 ms at max +Input response time
A
pprox.0.5 ms
A
pprox.2.5 ms
A
ppro
x
.20 ms
A
ppro
x
.250 ms
2 000 times/s：
400 times/s：
50 times/s：
4 times/s：
A
pprox.0.25 ms
A
pprox.1 ms
A
pprox.10 ms
A
ppro
x
.50 ms
4 000 times/s：
1 000 times/s：
100 times/s：
20 times/s：
DATA
POL
P.C.
Changeable to approx.0.125 ms, approx.0.25 ms, approx.0.5 ms, approx.1.25 ms,
approx.5 ms, approx.10 ms, approx.25 ms or approx.125 ms.
ON
ON
