Minebea CSD-709 User Manual

1 Overview
9
1
Overview
1.1 Checking contents of package
Before using the CSD-709, be sure to check if the package contains all the items listed below.
 CSD-709: 1
 Startup Guide (in Japanese and English): 1 set each
 Midget fuse (2.5 A): 1
 Unit seal: 1
 External control input/output connector: 1
 Strain-gage-based transducer connector: 1
CAUTION
 The following components are contained in the package when options are mounted
to the CSD-709.
 Voltage output plug (component for CSD-709-29): 1
 Current output plug (component for CSD-709-07): 1
 BCD output plug (component for CSD-709-15/CSD-709-16): 1
 RS-232C plug (component for CSD-709-74): 1
 RS-422/485 plug (component for CSD-709-76): 1
 Serial interface plug (component for CSD-709-77): 1
 CC-Link plug (component for CSD-709-73): 1
 Application CD-ROM (medium for CSD-709-91): 1
 USB cable (component for CSD-709-91): 1
1.2 Connectable components
A strain-gage-based transducer, such as a load cell or pressure sensor, can be connected to the
CSD-709. A PC and printer can also be connected. Shown below are the components that can be
connected to the CSD-709.
Strain-gage-
based transducer
RS-232C
RS-422/485
BCD
CC-Link
SI/F
USB
Measuring devices such as a
voltmeter, ammeter, or data
logger
External control devices such as
a PLC
Printer and display
PC (for additional memory or
PC application)
Voltage/current output
