10 Communications via USB
115
10
Communications via USB
10.1 Communication specifications
The CSD-709 is equipped with a USB interface conforming to the USB2.0 standard. The table below
shows the communication specifications of the USB interface.
Item Details
Output connector B type mini-USB connector
Transmission Half-duplex
Sync mode Asynchronous
Baud rate Select 1 200 bps, 2 400 bps, 4 800 bps, 9 600 bps, 19 200 bps, 38 400 bps,
57 600 bps, or 115 200 bps.
Data bit length Select 7 bit or 8 bit.
Parity bit Select No parity, Even parity, or Odd parity.
Stop bit Select 1 bit or 2 bit.
Terminator Select CR or CR+LF.
Communication ASCII code
Address 00 (Fixed)
Communication Command mode or Stream mode
CAUTION
To use the USB interface, you must install the specialized driver to the PC used as
host.
POINT
The USB interface of the CSD-709 accepts the device designed under the USB1.1 standard as
well.
