Minebea CSD-709 User Manual

I RS-422/485 Card CSD-709-76
182
I.2 Communication specifications
Item Details
Transmission Half-duplex
Sync mode Asynchronous
Baud rate
Select 1 200 bps, 2 400 bps, 4 800 bps, 9 600 bps, 19 200 bps,
38 400 bps, 57 600 bps, or 115 200 bps.
Data bit length Select [7 bit] or [8 bit].
Parity bit Select [No parity], [Even parity], or [Odd parity].
Stop bit Select [1 bit] or [2 bit].
Terminator Select [CR] or [CR+LF].
Communication data ASCII code
Address Select any value between 00 and 31.
Communication mode [Command mode] or [Stream mode]
