8 Settings Related to Output Control
104
8
Settings Related to Output Control
8.1 External control input signal
The CSD-709 can respond to up to six external contact inputs. You can assign the following functions
to these contact inputs.
Function Input type
Designate zero set. Pulse
Designate zero set clear.
Pulse
Designate hold (level).
Level
Designate hold (pulse).
Pulse
Designate PEAK/TRACK.
Level
Designate RESET.
Level
Designate SEL1.
Level
Designate SEL2.
Level
Designate CHECK value.
Level
Designate comprehensive key lock.
Level
Print command (through serial interface), Print command synchronization mode
Pulse
Designate forced termination of multimode.
Pulse
These functions can be set to functions F-60 to F-65 as operations of INPUT1 to INPUT6,
respectively. You can also set response times against these operating signals to function F-69.
Described below are the external control input setting procedures.
POINT
Do not assign the same set value to multiple PIN numbers.This instrument does not work properly.
To select designation of SEL1 or SEL2, combine the two statuses as shown below and specify the
change in calibration number.
Refer the [10.3 Data format] for Print command synchronization mode.
Status of SEL1 Status of SEL2 Calibration number to be changed
Open Open 0
Short Open 1
Open Short 2
Short Short 3
For the wiring for the external control input, see Section 2.2.3,
"
Plugging in the external control input/output connector
".
For more information on functions available in the external control input, see the descriptions in the sections listed below.
Function Referent
Designate zero set. 7.8 Zero set and effective range
Designate zero set clear. 7.8 Zero set and effective range
Designate hold (level). D.1 Detection operation
Designate hold (pulse). D.1 Detection operation
Designate PEAK/TRACK. D.1 Detection operation
Designate RESET. D.1 Detection operation
Designate SEL1. 3.2 Changing the calibration numbe
Designate SEL2. 3.2 Changing the calibration numbe
Designate CHECK value.
7.6 Output of CHECK value
Designate comprehensive key lock. 7.3 Loc
Print command (through serial interface), Pront command synchronization mode K.3 Setting
Designate forced termination of multimode. 5.2 Detection with multimode
[F-60] to [F-65], [F-69]
