J Communications Based on Modbus Protocol
194
J.4 Calibration based on Modbus
Using the following addresses in the hold register, you can execute remote calibration through the
Modbus protocol.
Address Data
53249 Calibration number
56833 Operating modes
56835 ~ 56836
Unit weight
56837 ~ 56838
Setting of measuring weight
56839 ~ 56840
Setting of weight mass
56841 ~ 56842
Registration of zero point load cell output
56843 ~ 56844
Registration of span point load cell output
56845 Actual load based calibration — Under AD reading
56846 Actual load based calibration — Registration of zero point
56847 Actual load based calibration — Registration of span point
56848 Calibration complete
56849 Zero point fine adjustment
56850 Span point fine adjustment
56857 ~ 56858
Fine adjustment mode, load display
Described below are the calibration procedures when the Modbus protocol is used.
J.4.1 Calibration based on actual load
1. Set [9] to address 56833 (Operating modes) to enter Calibration mode.
POINT
When [0] is set to address 56833, you can terminate calibration. In this case, all settings
established beforehand will be abandoned.
2. Set the calibration number to address 53249.
3. Set the unit weight to address 56835 ~ 56836.
4. Set the measuring weight to address 56837 ~ 56838.
5. Set the weight mass to address 56839 ~ 56840.
6. Set [1] to address 56846 (Actual load based calibration - Registration of zero point).
7. Refer to address 56845 (Actual load based calibration - Under AD reading) to check the setting
is [0].
8. Set [1] to address 56847 (Actual load based calibration - Registration of span point).
9. Refer to address 56845 (Actual load based calibration - Under AD reading) to check the setting
is [0].
10. Set [1] to address 56848 (Calibration complete).
