J Communications Based on Modbus Protocol
195
J.4.2 Calibration based on numerical value input
1. Set [9] to address 56833 (Operating modes) to enter Calibration mode.
POINT
When [0] is set to address 56833, you can terminate the calibration. In this case, all settings
established beforehand will be abandoned.
2. Set the calibration number to address 53249.
3. Set the unit weight to address 56835 ~ 56836.
4. Set the measuring weight to address 56837 ~ 56838.
5. Set the weight mass to address 56839 ~ 56840.
6. Set the mV/V value of the zero point to address 56841 ~ 56842 in 0.0001 mV/V increment.
7. Set the mV/V value of the span to address 56843 ~ 56844 in 0.0001 mV/V increment.
8. Set [1] to address 56848 (Calibration complete).
J.4.3 Fine adjustment
1. Set [10] to address 56833 (Operating modes) to enter Fine adjustment mode.
POINT
When [0] is set to address 56833, you can terminate the calibration. In this case, all settings
established beforehand will be abandoned.
2. Set the calibration number to address 53249.
3. Using address 56857 ~ 56858 (Fine adjustment mode, load display), refer to the currently set
load.
4. Enter any of the following values to address 56849 to fine-adjust the zero point.
Setting Fine adjustment
1
Slightly increases the adjustment amount.
10 Increases the adjustment amount.
-1
Slightly decreases the adjustment amount.
-10
Decreases the adjustment amount.
To Next Page
