Function Setting Table
206
Function Setting details Setting Default Referent
F−71
Setting of OUTPUT2
operation
Ditto 00 (Off) 8.2 External control
output signal
F−72
Setting of OUTPUT3
operation
Ditto 00 (Off) 8.2 External control
output signal
F−73
Setting of OUTPUT4
operation
Ditto 00 (Off) 8.2 External control
output signal
F−74
Setting of OUTPUT5
operation
Ditto 00 (Off) 8.2 External control
output signal
F−75
Setting of OUTPUT6
operation
Ditto 00 (Off) 8.2 External control
output signal
F−82 OUTPUT - Output
logic
0 (Negative logic),
1 (Positive logic).
First digit: OUTPUT1,
Second digit: OUTPUT2,
Third digit: OUTPUT3,
Fourth digit: OUTPUT4,
Fifth digit: OUTPUT5
00000 8.2 External control
output signal
F−83 OUTPUT - Output
logic
0 (Negative logic),
1 (Positive logic).
OUTPUT6
0 8.2 External control
output signal
F−84 CC-Link - Number
of shared stations
0 (One station is shared)
1 (One station is shared)
2 (One station is shared)
2 (4 stations
are shared)
F−85 CC-Link - Station
number
01 to 64 when one station is
shared.
01 to 63 when two stations are
shared.
01 to 61 when four stations are
shared.
1 (01)
F−86 CC-Link - Baud
rate
0 (156 kbps), 1 (625 kbps),
2 (2.5 Mbps), 3 (5 Mbps),
4 (10 Mbps)
0 (156 kbps)
F−87 CC-Link - 32 bit
data
representation
method
0 (Standard binary
representation)
1 (At minus, The most
significant digit is fixed to [8].)
0 (Standard
binary
representation)
F−89 Change method of
calibration data
and comparator
brand code
0 (Change with CF-18),
1 (Change with external
control input),
2 (Change with USB-based
communications),
3 (Change with option-based
communications)
0 (Change with
CF-18)
3.2 Changing the
calibration number
F−92 Calendar time
adjustment (year)
15
F−93 Calendar time
adjustment (month
and date)
0101
F−94 Calendar time
adjustment (hour
and minute)
0000
To Next Page
