D Detection Operation and Section
156
D.2.4 Automatic start time-specified section
In the automatic start time-specified section, the detection operation is initiated when the track
crosses the threshold (automatic start level) set to P function PF-41. This time, the section
determined by the time period set to P function PF-40 will be the detection section.
In the automatic start time-specified section, the detection operation is initiated when the track
crosses the threshold (automatic start level) set to P function PF-41 as shown below.
When the track reaches the threshold but does not cross it as shown below, the detection operation
is not initiated.
Threshold
Threshold
Detection operation section
Set time period
Threshold
