G BCD Card CSD-709-15/CSD-709-16
174
BCD output (sink type)
Pin No. Output/Input Signal Pin No. Output/Input Signal
A1
－
COM. B1
－
COM.
A2 Output
1×10
0
B2 Output
2×10
0
A3 Output
4×10
0
B3 Output
8×10
0
A4 Output
1×10
1
B4 Output
2×10
1
A5 Output
4×10
1
B5 Output
8×10
1
A6 Output
1×10
2
B6 Output
2×10
2
A7 Output
4×10
2
B7 Output
8×10
2
A8 Output
1×10
3
B8 Output
2×10
3
A9 Output
4×10
3
B9 Output
8×10
3
A10 Output
1×10
4
B10 Output
2×10
4
A11 Output
4×10
4
B11 Output
8×10
4
A12 Input SEL.1 B12 Input SEL.2
A13 Output POL. B13 Output OVER
A14 Output ERROR B14 Output P.C.
A15 Input HOLD B15 Input BCD-ENABLE
A16
－
N.C. B16
－
N.C.
BCD output (source type)
Pin No. Output/Input Signal Pin No. Output/Input Signal
A1
－
+24V B1
－
+24V
A2 Output
1×10
0
B2 Output
2×10
0
A3 Output
4×10
0
B3 Output
8×10
0
A4 Output
1×10
1
B4 Output
2×10
1
A5 Output
4×10
1
B5 Output
8×10
1
A6 Output
1×10
2
B6 Output
2×10
2
A7 Output
4×10
2
B7 Output
8×10
2
A8 Output
1×10
3
B8 Output
2×10
3
A9 Output
4×10
3
B9 Output
8×10
3
A10 Output
1×10
4
B10 Output
2×10
4
A11 Output
4×10
4
B11 Output
8×10
4
A12 Input SEL.1 B12 Input SEL.2
A13 Output POL. B13 Output OVER
A14 Output ERROR B14 Output P.C.
A15 Input HOLD B15 Input BCD-ENABLE
A16
－
0 V B16
－
0 V
CAUTION
 The card is insulated from the internal circuit of the CSD-709 by means of a photocoupler.
 Only BCD-ENABLE (pin number B15) of the source type becomes effective at the [OPEN].
Use this function after short-circuiting B15 and A1 or B1 when you do not use it.
