3 - 19
DIAGRAMS
Jam
code
Method of clearing jam
The main body is
stopped immediately.
Open ADU/main body
front door/lengthwise
conveyance door and
remove jammed paper,
and close it.
J92
J93
J94
J95
J96
Classifica-
tion
PS152 (ADU paper feed) is not
turned ON within 2000 msec from
ON of PS25 (paper exit).
During idling, PS152 (ADU paper
feed), PS153 (ADU reversal) or
PS157 (ADU gate) is ON.
PS157 (ADU gate) is turned ON
within 280 msec from the copy start.
CL151 (ADU paper feed) is not
turned OFF within 1500 msec from
ON of PS152 (ADU paper feed).
PS154 (ADU paper exit 1) is not
turned ON within 640 msec from
OFF of PS152 (ADU paper feed).
PS156 (ADU paper exit 3) is not
turned ON within 900 msec from ON
of PS154 (ADU paper exit 1).
During idling, PS154 (ADU paper
exit 1), PS155 (ADU paper exit 2),
PS156 (ADU paper exit 3) or PS151
(ADU no paper) is ON.
PS153 (ADU reversal) is OFF after
140 msec from OFF of PS152 (ADU
paper feed).
Causes
Operation when jam
occurs
ADU
paper feed
jam
ADU
paper exit
jam
When
operating
When
stationary
When
operating
When
stationary
When
operating
ADU
