Mita PointSource Ai 5555 - Center Cross-Section

2 - A - 4
MAIN BODY
ADF
Image read unit
Image write unit
Developing unit
Upper tray
2nd paper feed unit
Transfer corona unit
TSL
Separation corona unit
LCT-1000 tray
LCT-1500 tray
Lower tray
Conveyance unit
ADU paper exit/
conveyance unit
Fixing unit
Exposure lamp
PCL
Image processing section
Paper feed section
Cleaning section
Charging
corona unit
ADU paper feed/
conveyance section
CENTER CROSS-SECTION
