Mita PointSource Ai 5555 - Adu Timing Chart

3 - 55
Symbol
SD152
M152
M151
CL151
CL152
CL153
PS25
PS152
PS153
PS154
PS155
PS156
PS18
PS19
FM153
FM154
ADU gate SD
ADU fan motor
ADU paper feed motor
ADU paper feed CL
ADU reversal CL
ADU timing CL
Paper exit PS
ADU paper feed PS
ADU reversal detection PS
ADU paper exit PS1
ADU paper exit PS2
ADU paper exit PS3
No feed
Optics sync. PS
ADU cooling fan 1
ADU cooling fan 2
Item
Time (sec)
0
Copy ON
(sec)
When PS14 (registration) is turned ON by
the final sheet of copy paper.
12345
570mS
1070mS
200mS 200mS
570mS
ADU TIMING CHART (A4/8
1
/
2
" × 11", TWO ORIGINALS, TWO SHEETS SET)
