LCT-1500 TRAY PAPER FEED/CONVEYANCE SECTION
[3] Disassembly and Re-assembly
1. Removing and Re-installing the 1500 Tray
Paper Feed/Conveyance Section
Caution: Be sure that the power cord has been unplugged
from the power outlet.
a. Procedure
(1) Withdraw the LCT1000 tray/LCT1500 tray in the for-
ward direction.
(2) Withdraw the LCT1500 tray paper feed/conveyance
section in the forward direction, then withdraw it further
and lift it out.
(3) Remove the two stop rings, then shift the left and right
shaft bearings to the outside, and remove the 1st paper
feed roller unit.
(3) Re-install the 1500 tray paper feed/conveyance sec-
tion in the opposite sequence to removal.
2. Replacing the Rubber of the Paper Feed Roller
and Feed Roller
a. Procedure
(1) Remove the LCT1500 paper feed/conveyance sec-
tion.
(2) Remove the two set screws, then remove the convey-
ance cover.
Conveyance cover
Set screw
Feed roller
Shaft bearing
Paper feed roller
Shaft bearing
Stop ring
(4) Pull out the three Stop rings, the three shaft bearings,
the paper feed reference actuator and the two shafts of
the paper feed roller unit, then remove each roller.
(5) Remove the rubber from each roller (feed rubber A and
the double feed prevention rubber).
LCT1500 tray paper
conveyance section
Stop ring
Paper feed
reference
actuator
Paper feed roller
Feed rubber/A
Blue mark
Bearing
Stop ring
Stop ring
Bearing
Stop ring
Blue mark
Feed roller
Paper feed drive belt
Double feed prevention rubber
Paint mark
Bearing
(6) Re-install the rubber in the opposite sequence to
removal.
Caution: Ensure that the mounting direction of the rubber is
correct.
Set screw
