Mita PointSource Ai 5555 - 1500-Tray Paper Feed;Conveyance Drive; 1500-Tray Paper Feed;Conveyance Drive. 2

2 - B - 7
DRIVE SYSTEM DIAGRAM
[7] 1500-Tray Paper Feed/Conveyance Drive
C
B
Timing belt
LCT paper feed motor (M140)
LCT 1st paper feed CL (CL2)
Horizontal conveyance
rollers
Timing belt
Paper feed roller
Feed roller
Double feed prevention roller
DRIVE SYSTEM DIAGRAM-1
