ADJUSTMENT
4 - 10
* 2: Finisher sensor failure sensing.
Mode 1-6 1-5
Lower limit sensor sensing 0 0
Lower limit sensor sensing 0 1
Abnormal drop sensing
Upper limit sensing
Lower limit sensor sensing 1 0
Abnormal drop sensing
Upper limit sensing
Number of copies overrun sensing
* 3:
Finisher sub-tray select.
Mode 2-1 2-0
Does not 0 0
Sub-tray (Exits sheets face down) 0 1
Sub-tray (Exits sheets face up) 1 0
* 5: Toner level sensing (toner replenish display)
Caution: When making large volumes of copies, density may
lower in some cases when the set value is increased.
Mode 4-1 4-0
After 100 copies 0 0
After 1000 copies 0 1
After 2000 copies 1 0
After 3000 copies 1 1
* 6: Destination select
Mode 4-3 4-2
Japan 0 0
USA 0 1
Europe/others 1 0
* 7: Polygon motor low-speed timing
Mode 4-7 4-6
15 sec. after job end 0 0
30 sec. after job end 0 1
60 sec. after job end 1 0
120 sec. after job end 1 1
* 8: F4 size setting
Mode 5-1 5-0
8
1
/
2
" × 13" 0 0
8
1
/
4
" × 13" 0 1
8
1
/
8
" × 13
1
/
4
"10
8" × 13" 1 1
* 9: Polygon motor low-speed select (when idling)
Mode 5-5 5-4 5-3
No preliminary rotation 0 0 0
Preliminary rotation 14,000rpm 0 0 1
Preliminary rotation 11,024rpm 0 1 0
Preliminary rotation 8,000rpm 0 1 1
Stop 1 0 0
* 10: Original leading edge timing (amount of ADF leading edge
erasure)
Mode 5-7 5-6
2 mm 0 0
3 mm 0 1
4 mm 1 0
5 mm 1 1
* 11: Separator claw ON setting
Caution: Separator jams occur in some cases when the set-
ting is changed.
Mode 6-3 6-2 6-1 6-0
0 mm 0000
5 mm 0001
10 mm 0010
15 mm 0011
20 mm 0100
25 mm 0101
30 mm 0110
35 mm 0111
40 mm 1000
45 mm 1001
50 mm 1010
55 mm 1011
60 mm 1100
65 mm 1101
70 mm 1110
75 mm 1111
* 11: Separator claw OFF setting
Caution: Separator jams occur in some cases when the set-
ting is changed.
Mode 6-7 6-6 6-5 6-4
50 mm 0000
55 mm 0001
60 mm 0010
65 mm 0011
70 mm 0100
75 mm 0101
80 mm 0110
85 mm 0111
90 mm 1000
95 mm 1001
100 mm 1010
105 mm 1011
110 mm 1100
115 mm 1101
120 mm 1110
125 mm 1111
* 1: Finisher number of stapled sheets upper limit select
Mode 1-4 1-3
50 sheets 0 0
45 sheets 0 1
40 sheets 1 0
35 sheets 1 1
ADJUSTMENT-1
