M
ODEL M695 EXPANSION MODULE
Model M695 Expansion Module
The 6930 SIP IP phone offers two optional expansion modules that attach to the right side of the phone
to provide additional programmable keys.
The M695 provides three pages of 28 softkeys (for a total of 84 programmable softkeys), with each
softkey providing an LED and graphical UI for call status indication. The M695 features a 4.3” 480x272
pixel color backlit LCD display.
The M695 Expansion Module keys support the following functions:
• None • Speed Dial/Conf
• Line • Speed Dial/MWI
• Speed Dial • Directory
• (DND) • Filter
• Busy Lamp Field (BLF) • Callers List
• BLF/List • Redial
• Auto Call Distribution (ACD) • Conference
• Extensible Markup Language (XML) • Transfer
• Flash • Intercom (Icom)
• Sprecode • Phone Lock
• Park • Paging
• Pickup • Login
• Last Call Return • Discreet Ringing
