ONFIGURING SOFTKEYS SOFTKEY DISPLAY BEHAVIOR
In the Mitel Web UI, the operational states for each softkey display as enabled. To disable a state, simply
uncheck the box for the respective state.
Softkey Display Behavior
On the 6930 IP phone, you can configure up to 44 (top) and 24 (bottom) functions on the softkeys. By
default, if you have no softkeys configured on the IP phone, and you assign softkey functions to higher
number keys in the Mitel Web UI, the key functions automatically appear in the first available position on
the LCD display.
For example, if top softkeys 1 through 44 are set to None, and you set the top softkey 12 as the following:
Type: Speed DialLabel: John DoeValue: 3456
after saving the settings, the “Home” label actually appears in position 1 of the LCD.
A softkey function of Nonedoes not display on the Home screen at all.
The following figures illustrate the above scenario (i.e. the configuration of top softkey 12) and how it is
displayed on the phone:
Speed Dial/MWI Idle, Connected, Incoming, Outgoing, Busy
Directory Idle, Connected, Incoming, Outgoing, Busy
Filter Idle, Connected, Incoming, Outgoing, Busy
Received Callers List Idle, Connected, Incoming, Outgoing, Busy
Outgoing Redial Idle, Connected, Incoming, Outgoing, Busy
Conference Idle, Connected, Incoming, Outgoing, Busy
Transfer Idle, Connected, Incoming, Outgoing, Busy
Intercom Idle, Connected, Incoming, Outgoing, Busy
Phone Lock All states disabled.
Paging All states disabled.
Login Idle, Connected, Incoming, Outgoing, Busy
Discreet Ringing Idle, Connected, Incoming, Outgoing, Busy
Call History Idle, Connected, Incoming, Outgoing, Busy
Empty Idle, Connected, Incoming, Outgoing, Busy
Softkey Type Default States
