Mitsubishi GOT1000 GT11 - Page 222

App - 6
Appendix 1 External Dimensions
#4-40UNC
M2.6
30000(1181.1")50(1.97") 53(2.09")
55(2.17")
16
(0.63")
16
(0.63")
35(1.38")
6
#4-40UNC
#4-40UNC
30000(1181.1")50(1.97") 50(1.97")
16
(0.63")
16
(0.63")
35(1.38") 35(1.38")
6
GT01-C30R2-25P
GT01-C30R2-9S
30000(1181.1")50(1.97")
16
(0.63")
35(1.38")
7
(0.28")
40(1.58")
#4-40UNC
20 28
(0.79") (1.11")
13
(0.52")
GT01-C30R2-6P
