Motorola APEX1000 User Manual

B
Configuration • RADIUS Authentication
APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
93
573408-001-a
RADIUS Configuration window field definitions
Parameter Description
Enable
Place a checkmark in this box to enable RADIUS log in.
Range: Enabled/Disabled
The default is Disabled.
Primary Server IP
IP address of the primary RADIUS server.
Range: Unicast IPv4 address
The default is 0.0.0.0.
Primary UDP Port
Authentication/Authorization port for primary server.
Range: 1 – 65535
The default is 1812.
Primary Shared Secret
Displays the shared secret for the primary server.
Range: 127 char string
The default is empty string.
*** allows the root or administrator user to view the shared secret.
Secondary Server IP
IP address of the secondary RADIUS server.
Range: Unicast IPv4 address
The default is 0.0.0.0.
Secondary UDP Port
Authentication/Authorization port for secondary server.
Range: 1 – 65535
The default is 1812.
Secondary Shared Secret
Displays the shared secret for the secondary server.
Range: 127 char string
The default is empty string.
*** allows the root or administrator user to view the shared secret.
Server Timeout
Timeout before retrying. (Must be greater than two seconds to allow
time for SecurID server to generate a response.)
Range: 5 s – 600 s
The default is 5 s.
Maximum Retries
Allowable number of retries per server.
Range: 0 – 5
The default is 3.
Local Failback
Allows for local authentication if RADIUS authentication fails.
Range: Enabled/Disabled
The default is Enabled.
NAS IP Interface
Selects which interface IP address is included in the NAS IP attribute in
RADIUS messages.
Range: ENET1/ENET2
The default is ENET1.
