B
SimulCrypt • EIS Configuration
APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
198
573408-001-a
3. Repeat step 2 for each selected row.
4. Click Apply.
5. Click Refresh to update the screen.
Note: When you enable a row, it moves to the Active Mappings panel.
SCG Provisioning window field definitions
Item Definition/Range
Active/Available Entries
Index
Identifies the window line item.
Enable
A check mark indicates that the provisioning defined in the line is enabled.
Output TS
Specifies the output transport stream where the service to be scrambled
belongs.
Range: 1 – 48
Note: Only output transport streams that are configured as SimulCrypt enabled
can be used to define a scramble provisioning.
All Svcs
A check mark indicates that all services transmitted through the specified output
transport stream must be scrambled.
Single SCG
A check mark indicates that only one scrambling group will be created (one single
connection with each ECMG, for example) so that all the services within the
specified output transport stream share the same control word.
Note: This option is only available if the All Svcs checkbox is marked.
Svc ID
Identifies the service that has to be scrambled within the specified output
transport stream (1 – 65535).
Note: This option is only available if the All Svcs checkbox is not marked.
SuperCAS list
Each column appears referring to one of the SuperCAS configured
(CAS_id/subsystem_id).
A check mark in any of the columns indicates that the corresponding SuperCAS
must be contacted to perform scrambling for the specified services in that output
transport stream.
