APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
210
573408-001-a
EIS Statistics window field definitions
Item Definition/Range
Status
Shows the EIS connectivity operational status.
Values are:
• notApplicable
• idle
• setup
• close
EIS Channel
Fault
Shows the EIS connectivity status.
Values are:
• ok
• indeterminate
• warning
• minor
• major
• critical
Active
Displays the number of scrambling groups currently
active.
SCG
Inactive
Displays the number of scrambling groups currently
provisioned but not active.
Received
Counter for the channel errors received from the EIS
entity.
Channel Errors
Sent
Counter for the channel errors reported to the EIS entity.
SCG Errors Sent
Counter for the scrambling group specific errors reported
to the EIS entity.
Index
Identifies the window line item.
SCG ID
Identifies a specific scrambling group.
Activation Time
Indicates the time for activation of the specific scrambling group.
If the scrambling group is provisioned but not yet active, the activation time
indicates a moment in the future.
Services
Number of services belonging to the specific scrambling group.
TS ID
Transport Stream linked to the specific scrambling group.
This value identifies one of the 48 output QAM channels existing in the APEX
(referenced with values 0 to 47 instead of 1 to 48).
Network ID
Identifier for the Network linked to the specific scrambling group.
Rec CP
Displays the recommended Crypto Period duration proposed by the EIS
entity for the specific scrambling group.
ECM Groups
Number of ECM groups belonging to the specific scrambling group.
