B
Appendix B • Alarms Window Field Definitions
APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
290
573408-001-a
Condition Description
Event or Alarm
(Severity Level)
Data Included in
Alarm or Event
Trap
Notes
Output Utilization
Output stream is above user
defined utilization threshold
Alarm
• Minor
Output TS # 1. Can be disabled
2. Trap sent on an Output
Transport basis
Output Overflow
Output stream has
overflowed (packets have
been dropped)
Alarm
• Critical
Output TS # 1. Can be disabled
2. Trap sent on an Output
Transport basis
QAM Module
QAM Module Fault detected
(QAM Module removed,
unsupported module
installed, no module
installed, power fault,
module offline)
• Major indicates QAM
channels were not active
when QAM Module first
entered a fault condition
• Critical indicates QAM
Channels were active
when QAM module first
entered a fault condition
Alarms
• Major
• Critical
Module Slot #
(1,2,3)
1. Can be disabled
2. Trap sent on a QAM
Module basis
QAM RF Port
QAM Port Fault detected
• Major indicates power
voltage or output RF level
• Critical indicates clock,
PLL, or data sync
Alarms
• Major
• Critical
RF Port #
(1,2,3,4,5,6)
1. Can be disabled
2. Trap sent on a RF Port
basis
QAM Channel
QAM Channel Fault detected
Critical, indicates data fault
Alarm
• Critical
Output TS # 1. Can be disabled
2. Trap sent on a QAM
Channel basis
RDS Alarms
RDS
Communication
Alarm
Problem communicating with
RDS after three (3) polling
attempts
Alarm
• Major
Affected output
TS and/or SN
Clears upon successful
communication
Session Control Alarms
RTSP Controller
Alarm
Failure to communicate with
RTSP controller
Alarm
• Major
None Can be disabled
Init Alarms
