Motorola APEX1000 - RF Redundancy Alarms

B
Appendix B • Alarms Window Field Definitions
APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
291
573408-001-a
Condition Description
Event or Alarm
(Severity Level)
Data Included in
Alarm or Event
Trap
Notes
Invalid Init Data
Invalid configuration data on
initialization
Occurs only at APEX bootup
Alarm
• Warning
None 1. Indicates that the APEX
is not properly configured
2. Can be disabled
3. Can be cleared
4. Overall alarm - 1 alarm
for all invalid data
RF Redundancy Alarms
REM1000 Comm
Fault
REM Communication Fault
Major when experiencing
an REM communication
fault
Alarm
• Major
N/A 1. Can be disabled
2. Clears when REM
connection is restored
REM1000 Fault
REM Fault
Major when error received
from REM or REM is
reporting incorrect switch
configuration
Alarm
• Major
1. Can be disabled
2. Clears when REM
errors clear
Port
Failover/Switchback
QAM RF Redundancy
Failover Alarm
Major when the backup
QAM RF Port status is
active
Occurs when a primary
QAM RF Port has failed
over to the backup RF Port
or the user has forced a
primary to the backup
Alarm
• Major
1. Clears when the backup
QAM RF Port status
returns to ‘standby’
2. Can be disabled
APEX RF Port
Mismatch
QAM RF Redundancy
Mismatch Alarm
Warning when channels
could be lost on QAM RF
Fail Over to backup or on
Switch Back to primary
Alarm
• Warning
1. Clears when mismatch
condition is corrected
2. Can be disabled
SimulCrypt Alarms
ECMG Channel
• Minor when Active ECMG
Channel is not setup but a
Backup ECMG Channel is
configured and setup
• Major when both Active
and Backup ECMG
Channels are not setup
Alarms
• Minor
• Major
Event generated
identifying the
Impacted ECMG
channel
1. Can be disabled
2. Clears automatically
when all configured
ECMG Channels are setup
or if Channel is Disabled
by user
3. Overall alarm – 1 alarm
for all ECMG channels
