Overview • Operating Modes
APEX1000 All-Purpose Edge QAM Software Version 2.4.x • Installation and Operation Manual
18
573408-001-a
The following table briefly describes the various interfaces shown in the preceding
figure:
Interface Name Description Related/Underlying Protocols
S1
Session control between Session Manager
and Client (STB)
RTSP and/or DSM-CC
S3
Session control between Session Manager
and VOD server
Based on RTSP
S4
Session control between Session Manager
and Encryption Resource Manager (EnRM)
Based on RTSP
S6
Session control between Session Manager
and Edge Resource Manager (ERM1000)
Based on RTSP
R3
Encryption Control Word exchange between
ECMG and encryptor (essentially the SCS-
ECMG SimulCrypt interface with some
extensions)
ECMG-SCS SimulCrypt
R4
Right Meta Data (RMD) provided from EnRM
to encryptor
RTSP
R6
Session signaling between ERM1000 and
Edge QAM
Based on RTSP
D6
Auto-discovery from Edge QAM to ERM1000 Based on VREP
D7
Auto-discovery from encryptor to EnRM Based on VREP
V1
Video streams at the output of the VOD
server
SPTS MPEG/UDP/IP over GigE
V2
Encrypted Video streams at the output of the
encryptor
SPTS MPEG/UDP/IP over GigE
V3
Video streams as carried over the IP/GigE
network
SPTS MPEG/UDP/IP over GigE
V4
Video over QAM to HFC network MPTS over QAM
From the perspective of the APEX1000, the major RTSP/MHA VOD control interfaces are
R6 and D6 from the Edge Resource Manager (ERM1000).
• The ERM1000 uses D6 to discover the Edge QAM (the APEX1000) and its
capabilities.
• R6 routes individual VOD sessions through the APEX1000, from an SPTS input at the
GigE interface to a program in an MPTS QAM output.
The other interfaces shown above relate to other functions and components in the
RTSP/MHA network, from the STB client, to the VOD streaming server, to the encryptor.
These are all controlled by the Session Manager.
