Motorola MTX series Programmer's Reference Guide

Raven Interrupt Controller Implementation
http://www.motorola.com/computer/literature 2-59
2
TIMER 3 DESTINATION REGISTER $011f0
INT. SRC. 0 VECTOR-PRIORITY REGISTER $10000
INT. SRC. 0 DESTINATION REGISTER $10010
INT. SRC. 1 VECTOR-PRIORITY REGISTER $10020
INT. SRC. 1 DESTINATION REGISTER $10030
INT. SRC. 2 VECTOR-PRIORITY REGISTER $10040
INT. SRC. 2 DESTINATION REGISTER $10050
INT. SRC. 3 VECTOR-PRIORITY REGISTER $10060
INT. SRC. 3 DESTINATION REGISTER $10070
INT. SRC. 4 VECTOR-PRIORITY REGISTER $10080
INT. SRC. 4 DESTINATION REGISTER $10090
INT. SRC. 5 VECTOR-PRIORITY REGISTER $100a0
INT. SRC. 5 DESTINATION REGISTER $100b0
INT. SRC. 6 VECTOR-PRIORITY REGISTER $100c0
INT. SRC. 6 DESTINATION REGISTER $100d0
INT. SRC. 7 VECTOR-PRIORITY REGISTER $100e0
INT. SRC. 7 DESTINATION REGISTER $100f0
INT. SRC. 8 VECTOR-PRIORITY REGISTER $10100
INT. SRC. 8 DESTINATION REGISTER $10110
INT. SRC. 9 VECTOR-PRIORITY REGISTER $10120
INT. SRC. 9 DESTINATION REGISTER $10130
INT. SRC. 10 VECTOR-PRIORITY REGISTER $10140
INT. SRC. 10 DESTINATION REGISTER $10150
INT. SRC. 11 VECTOR-PRIORITY REGISTER $10160
INT. SRC. 11 DESTINATION REGISTER $10170
INT. SRC. 12 VECTOR-PRIORITY REGISTER $10180
INT. SRC. 12 DESTINATION REGISTER $10190
INT. SRC. 13 VECTOR-PRIORITY REGISTER $101a0
Table 2-8. Raven MPIC Register Map (Continued)
3
1
3
0
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
9
1
8
1
7
1
6
1
5
1
4
1
3
1
2
1
1
1
09876543210
Off
