Motorola MTX series Programmer's Reference Guide

1-4 Computer Group Literature Center Web Site
Board Description and Memory Maps
1
Figure 1-1. MTX Series System Block Diagram
66MHz MPC604 Processor Bus
16M-128M DIMM Memory Socket
Debug Connector
Buffers
33MHz 32/64-bit PCI Local Bus
L2 Cache
Glance 256K
System
Registers
FLASH
5M
Clock
Generator
Processor 1
MPC604e
Memory Controller
Falcon Chipset
MPC/PCI & IC
Raven ASIC
Ethernet
DEC21140
SCSI
SYM53C875A
PIB
WINBOND
Floppy
64-bit PMC Slot
KBD
Mouse
ISA
Registers
RTC/NVRAM/WD
MK48T59
Super I/O
PC87308
Rear Panel
6
4
-
b
i
t
P
M
C
S
l
o
t
10/100BT
Serial#2
Serial#1
PIC
CL-CD1283
Peripheral Parallel
ESCC 85230
CIO Z8536
Serial#3
Serial#4
Parallel
16M-128M DIMM Memory Socket
16M-128M DIMM Memory Socket
16M-512M DIMM Memory Socket
Processor 0
MPC603e/604e
64-bit PCI Slot
RJ45
AUI
LED
SCSI-2 wide
Secondary EIDE Port
I2C
PCF8584
Primary EIDE Port
32-bit PCI Slot
32-bit PCI Slot
32-bit PCI Slot
Optional
Optional
