Raven PCI Host Bridge & Multi-Processor Interrupt Controller
2
Raven-Detected Errors Destination Register
This register indicates the possible destinations for the Raven detected
error interrupt source. These interrupts operate in the Distributed interrupt
delivery mode.
P1 PROCESSOR 1. The interrupt is pointed to processor 1.
P0 PROCESSOR 0. The interrupt is pointed to processor 0.
Interprocessor Interrupt Dispatch Registers
There are four Interprocessor Interrupt Dispatch Registers. Writing to an
IPI Dispatch Register with the P0 and/or P1 bit set causes an interprocessor
interrupt request to be sent to one or more processors.
Offset $10210
Bit 3
1
3
0
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
9
1
8
1
7
1
6
1
5
1
4
1
3
1
2
1
1
1
0
9876543210
Name RAVEN DETECTED ERROR DESTINATION
P1
P0
Operation RRRR
R/W
R/W
Reset $00 $00 $00 $00
0
0
Offset Processor 0 $20040, $20050, $20060, $20070
Processor 1 $21040, $21050,$21060, $21070
Bit 3
1
3
0
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
9
1
8
1
7
1
6
1
5
1
4
1
3
1
2
1
1
1
0
9876543210
Name IPI DISPATCH
P1
P0
Operation RRRR
R/W
R/W
Reset $00 $00 $00 $00
0
0
