Registers
http://www.motorola.com/computer/literature 2-37
2
PCI Registers
The PCI Configuration Registers are compliant with the configuration
register set described in the PCI Local Bus Specification, listed in
Appendix A, Related Documentation. The CONFIG_ADDRESS and
CONFIG_DATA registers described in this section are accessed within
PCI I/O space.
All write operations to reserved registers will be treated as no-ops. That is,
the access will be completed normally on the bus and the data will be
discarded. Read accesses to reserved or unimplemented registers will be
completed normally and a data value of 0 returned.
The Raven PCI Configuration Register map is shown in Table 2-6. The
Raven PCI I/O Register map is shown in Table 2-7.
Table 2-6. Raven PCI Configuration Register Map
3
1
3
0
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1
9
1
8
1
7
1
6
1
5
1
4
1
3
1
2
1
1
1
09876543210
<--- Bit
DEVID VENID $00
PSTAT PCOMM $04
CLASS REVID $08
HEADER $0C
IOBASE $10
MEMBASE $14
$18 - $7F
PSADD0 $80
PSOFF0 PSATT0 $84
PSADD1 $88
PSOFF1 PSATT1 $8C
PSADD2 $90
PSOFF2 PSATT2 $94
PSADD3 $98
PSOFF3 PSATT3 $9C
