Board Description and Memory Maps
1
SCSITS On board SCSI terminator status. If set, the on board terminator
is enabled. If cleared, the on board terminator is disabled.
SCSITP SCSI terminator power status. If set, SCSI terminator power is
available. If cleared, there is no SCSI terminator power.
SCSI Terminator Select
The SCSI terminator select register is a one-bit (SD15) write only register
located at ISA I/O address x0950. If a one is written to this register, the
SCSI terminator is disabled. If a zero is written to this register, the
terminator is enabled (assuming the on-board jumper described below is
not installed). This register is cleared by a hard reset (terminators are
enabled). This register may be overriden by installation of an on-board
jumper at J36. The jumper disables the on-board SCSI terminator,
regardless of the state of the terminator select register.
Register Extended Status Register - Offset $0951
Bit SD7 SD6 SD5 SD4 SD3 SD2 SD1 SD0
Field
SCSITS
SCSIP
Operation RRRRRRRR
Reset XXXXXXXX
