Motorola MTX series - Table 3-10. Powerpc 60 X to Rom;Flash Address Mapping When Rom;Flash Is 64 Bits Wide (32 Bits Per Falcon)

Functional Description
http://www.motorola.com/computer/literature 3-21
3
$XXFFFFFB $7FFFFF Upper
$XXFFFFFC $7FFFFC Lower
$XXFFFFFD $7FFFFD Lower
$XXFFFFFE $7FFFFE Lower
$XXFFFFFF $7FFFFF Lower
Table 3-10. PowerPC 60x to ROM/Flash Address Mapping when ROM/Flash
is 64 Bits Wide (32 Bits per Falcon)
PowerPC 60x A0-A31 ROM/Flash A22-A0 ROM/Flash Selected
$X0000000 $000000 Upper
$X0000001 $000000 Upper
$X0000002 $000000 Upper
$X0000003 $000000 Upper
$X0000004 $000000 Lower
$X0000005 $000000 Lower
$X0000006 $000000 Lower
$X0000007 $000000 Lower
$X0000008 $000001 Upper
$X0000009 $000001 Upper
$X000000A $000001 Upper
$X000000B $000001 Upper
$X000000C $000001 Lower
$X000000D $000001 Lower
$X000000E $000001 Lower
$X000000F $000001 Lower
$X3FFFFF0 $7FFFFE Upper
$X3FFFFF1 $7FFFFE Upper
Table 3-9. PowerPC 60x to ROM/Flash Address Mapping when ROM/Flash is
16 Bits Wide (8 Bits per Falcon) (Continued)
PowerPC 60x A0-A31 ROM/Flash A22-A0 ROM/Flash Selected
