Motorola MTX series Programmer's Reference Guide

1-2 Computer Group Literature Center Web Site
Board Description and Memory Maps
1
System Block Diagram
The MTX series provides the 256KB look-aside external cache option.
The Falcon chip set controls the boot Flash and the ECC DRAM. The
Raven ASIC functions as the 64-bit PCI host bridge and the MPIC
interrupt controller. PCI devices include: SCSI, Ethernet, and one PMC
RTC and
Watchdog Timer
MK48T59 Device
Memory
Controller
Falcon Chipset
PCI Host Bridge Raven ASIC
Interrupt
Controller
RavenMPIC (Raven ASIC)
PCI Interface 32/64-bit Data, up to 33 MHz operation
Form Factor ATX
Peripheral
Support
Two 16550-compatible async serial ports
Two sync/async serial ports
One Host-mode Parallel Port
One Peripheral-mode Parallel Port
8-bit or 16-bit single-ended SCSI interface
AUI or 10BaseT/100BaseTX Ethernet interface
One PS/2 Keyboard and one PS/2 Mouse
One PS/2 Floppy Port
Two EIDE ports
PCI/PMC
Expansion
Build option for two 32/64-bit PMC slots with back-panel I/O
Build option for one 32/64-bit PCI Connector for horizontal PCI card via
special riser
Build option for three 32-bit vertical PCI card slots with back panel I/O
Miscellaneous RESET/ABORT Switch
Status LEDs
Table 1-1. MTX Series Features Summary (Continued)
Feature Description

Motorola MTX series Specifications

General

Brand	Motorola
Model	MTX series
Category	Portable Radio
Language	English
