SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
TRANSMISSION
Ch 2 page 106 Ch 2 page 107
TRANSMISSION
TRANSMISSION
Ch 2 page 106 Ch 2 page 107
TRANSMISSION
Figure 24
Figure 26
Figure 25
Introduce cable harness and connect pressure regulators (6x).
Pay attention to the installation position of the cable harness, see
also markings (Figure 3) !
Locate the femal connector by means of retaining clip.
Install opposite cover.
Mount flat gasket (Arrow).
Introduce femal connector, with the groove facing the guide
nose of the cover, until contact is obtained.
Fasten cover with socket head screws.
Torque limit ...................................... 5,5 Nm
