SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
TRANSMISSION
Ch 2 page 166 Ch 2 page 167
TRANSMISSION
TRANSMISSION
Ch 2 page 166 Ch 2 page 167
TRANSMISSION
Figure 168
Figure 171
Figure 170
Figure 169
Carefully drive in roll pin (arrow) until contact is obtained.
Squeeze out snap ring (arrow) and separate output shaft from
planet carrier.
Press output shaft far enough downward until the sun gear can be
removed, also see Figure 171!
Drive out planet bolt and remove planet gears.
