SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
TRANSMISSION
Ch 2 page 164 Ch 2 page 165
TRANSMISSION
TRANSMISSION
Ch 2 page 164 Ch 2 page 165
TRANSMISSION
Figure 164
Figure 167
Figure 166
Figure 165
Pull bearing inner race off the internal gear.
(S) Quick-acting grip 504252
or grab sleeve 504247
(S) Basic tool 504246
Press internal gear and planet carrier out of the internal gear.
Figure 167 shows the released
components!
Squeeze out snap ring.
