Moxy MT 31 - Page 483

SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
TRANSMISSION
Ch 2 page 286 Ch 2 page 287
TRANSMISSION
TRANSMISSION
Ch 2 page 286 Ch 2 page 287
TRANSMISSION
Figure 564
Figure 567
Figure 566
Figure 565
Pull bearing inner race from differential housing.
Disassemble the opposite bearing inner race accordingly.
(S) Two-leg puller 504731
Separate crown wheel from differential housing, using back-off
screws.
(S) Back-off screws 505154
Loosen both socket head screws.
Loosen locking screws.
