SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
SHOP MANUAL MT26/31 - 08.2006 SHOP MANUAL MT26/31 - 08.2006
TRANSMISSION
Ch 2 page 288 Ch 2 page 289
TRANSMISSION
TRANSMISSION
Ch 2 page 288 Ch 2 page 289
TRANSMISSION
Figure 572
Figure 573
Press drive pinion out of the differential housing (Figure 572) and
disassemble both bearing outer races.
Pay attention to the released components !
Press bearing inner race from the drive pinion.
(S) Grab sleeve 8327
