TRANSMISSION
Ch 2 page 294 Ch 2 page 295
TRANSMISSION
TRANSMISSION
Ch 2 page 294 Ch 2 page 295
TRANSMISSION
Figure 591
Line up the clutch sleeve.
Mount disk and tighten slotted nut finally.
Wet thread of slotted nut with Loctite
(Type-No. 262) !
During the tightening, rotate the pinion
several times in both directions !
Torque limit ............................................. 1200 Nm
(S) Hook spanner 504726
(S) Counter support 504724
(S) Power amplifier 504719
