3-74

Attribute 1 - Individual Autodialer Setting (Equivalent to Memory Switch 010)

Switch

Initial

Setting

Adjust Usage/Comments

7 1 Busy tone detection

0: No

1: Yes

Sets this switch to “0” if the ring tone of remote unit

is mistaken for a busy signal.

6 0 Fallback pattern (bps)

2400 4800 7200 9600 14400

Set at 0: 2 times 2 times 2 times 2 times 2 times

Set at 1: 4 times 1 times 1 times 1 times 1 times

5 0 Overseas mode

0: No

1: Yes

Re-enables echo suppression that is disabled by

the CED signal (2100 Hz). Also ignores the ﬁrst DIS

signal and transmits the DCS signal in response to

the second DIS signal.

4 0 V.29 Echo Protect tone

0: No

1: Yes

International telephone lines equipped with echo

suppression will cut the beginning portion of the

transmitted information which may cause the

receiver not to receive the training and data. To

protect the received image from degrading, a 0.5

second Echo Protect tone is placed prior to the

training using G3 high-speed modem training

(V.29).

3 1 Maximum transmit speed (kbps)

2.4 4.8 7.2 9.6 12 14.4 16.8 19.2 21.6 24 26.4 28.8 31.2 33.6

2 1 0 0 0 0 0 0 0 0 1 1 1 1 1 1

0 0 0 0 1 1 1 1 0 0 0 0 1 1

1 0 0 0 1 1 0 0 1 1 0 0 1 1 0 0

0 1 0 1 0 1 0 1 0 1 0 1 0 1

0 1
