Muratec F-525 User Manual

5-15
5.2.2 PCBS
PCB NGP (See page 5-20)PCB NGP (See page 5-20)
PCB CONNECT B (See page 5-22)PCB CONNECT B (See page 5-22)
PCB DC/DCPCB DC/DC
PCB CONNECT C (See page 5-24)PCB CONNECT C (See page 5-24)
PCB PANEL 2 (See page 5-16)PCB PANEL 2 (See page 5-16)
PCB PANEL 1 (See page 5-16)PCB PANEL 1 (See page 5-16)
PCB INVERTER (See page 5-17)PCB INVERTER (See page 5-17)
PCB CCD (See page 5-29)PCB CCD (See page 5-29)
PCB CONNECT A (See page 5-22)PCB CONNECT A (See page 5-22)
PCB MAIN (See page 5-21)PCB MAIN (See page 5-21)
PCB NCL (See page 5-23)PCB NCL (See page 5-23)
PCB PSU (See page 5-23)PCB PSU (See page 5-23)
POWER-SUPPLY (See page 5-22)POWER-SUPPLY (See page 5-22)
