Adjust so that width A on the test pattern Checkered output falls within the following range.
Standard Adjustment Tool Setting Range
10 Ā± 1.5 (mm)
Machine parameter: 180, 220
0 to 12.7 (mm)
(0.1 mm step)
Machine parameter: 240
-12.8 to 12.7 (mm)
(0.1 mm step)
Adjustment procedure
1. Load legal (for USA version) or A4 (for GBR version) size paper to the cassette or tray you want
to adjust.
2. Use the Unique Switch 52 to adjust the printing margin to 0 mm. (bit 0, 1ļ0)
3. Printout the test pattern āLadderā. (Press <Setting> , <*> , <0> , <9> , [Test Pattern Print] ,
[Ladder].)
4. Check width A on the test pattern Ladder meets the speciļ¬cations.
If width A falls outside the speciļ¬ed range, perform following steps to make the adjustment.
5. To use the āPrinter registration mode,ā press <Setting> , <*> , <4> , <3> and then select the cas-
sette.
6. Select āVertical Regi ā, and then adjust the āVertical Registrationā.
If the width A is shorter than the standard, increase value.
If the width A is longer than the standard, decrease value.
7. After you have ļ¬nished the adjustment, you must reenter the setting of Unique Switch 52, you
changed in step 2.
Important: The setting you have entered in Printer registration mode is reļ¬ected in the following
Machine parameters.
Cassette 1: Machine parameter 180, 220, 240
Cassette 2: Machine parameter 181, 221, 241
Bypass Tray: Machine parameter 187, 227, 247
Duplex Unit: Machine parameter 188, 228, 248
ā¢ Machine Parameter 180 to 188 āā Adjust the start point to printing. (Vertical)
ā¢ Machine Parameter 220 to 228 āā Adjust the top margin.
ā¢ Machine Parameter 240 to 248 āā Adjust the bottom margin.
To Next Page
