6-1
6 Options
CAUTION: This installation should be done by an authorized Muratec technician.
6.1 Memory Upgrade
An optional 32 MB document memory upgrade is available.
6.1.1 Packaging contents:
1. Memory module (32 MB) ................................................1
6.1.2 Installation
1. Turn the machine off and unplug the power cord.
2. Remove the covers.
1) Remove one screw and the connect cover.
2) Unplug the harness that is going through the connect cover.
3) Remove two screws and the option cover.
4) Remove five screws and the shield cover.
4. Holding the memory module only by the edges, gently but firmly set the memory module to the
memory slot (P1 connector), then push it until it snaps.
