6-2
5. Reattach the PCB NGP and the covers.
6. Plug the power cord and turn the machine on.
7. Initialize the memory module by pressing <Setting>, <*>, <1>, <6>, and [Yes].
Note: This setting ( [DRAM clear] ) will erase all of stored documents in the machine’s memory.
8. Perform the memory test ( [DRAM clear] ) by the following procedure.
1) Press <Setting>, <*>, <1>, <1>, then select [DRAM Check] .
2) Use the numeric keys and one-touch keys [01] through [06] to enter Hex code (00 to FF), and
press <Start>.
Use the sharp key (#) to enter A, B, C, D, E and F. See table below.
A B C D E F
#, 0 #, 1 #, 2 #, 3 #, 4 #, 5
3) Enter RAM check area by number. (See table below)
Press Check area
0 All DRAMs
1 The standard memory on the main control board
2 The first half of the 32MB Optional Memory PCB
3 The second half of the 32MB Optional Memory PCB
4) Press <Start>.
5) The machine shows the checked result. Press <Reset> to go back to the standby mode.
9. Print the “Fax Settings List” by pressing <Setting>, [List], [Setting List], [Fax Setting], and [Yes] to
see the memory amount becomes 40960 KB (40 MB).
10. Turn the machine off.
11. Reattach the covers and the harness.
To Next Page
