5.1 Maintenance schedule
Scanning Section
Parts Name
Maintenance Cycle (pages)
QTY Reference Page
Clean Replace
Roller Separator*1
60,000 or
2 years
1 5-25
Pad Separator*1
60,000 or
2 years
1 5-37
Contact glass & Pane*2
Clean when
dirty
1
Sheet document press
(White sheet) *2
Clean when
dirty
1
Exposure Lamp*2 10,000 hours 1 5-19
Roller Feed
100,000 1 5-26
Roller Exit
100,000 1 5-28
*1 Replace these parts at the same time.
*2 It is not a maintenance parts. However, please replace when it becomes not works.
Printer Section
Parts Name
Maintenance Cycle (pages)
QTY Reference Page
Clean Replace
Roller Transfer 60,000 1 5-48
Roller Register
100,000 1 5-49
ASSY FUSER 100,000 1 5-53
Roller Exit
100,000 1 5-54
Roller Pickup MP
60,000 or
2 years
1 5-52
PAD Pressure MP
60,000 or
2 years
1 5-52
Roller Pickup CST
60,000 or
2 years
1 5-55
PAD Pressure CST
60,000 or
2 years
1 5-55
Roller Feed Duplex
(Duplex models only)
60,000 or
2 years
2 5-62
Developing Section
Parts Name
Maintenance Cycle (pages)
QTY Reference Page
Clean Replace
MFX-2050/1450 Drum cartridge 30,000 1
See Operating
Instructions
F-565/525 Drum cartridge 20,000 1
MFX-2050/1450 Toner cartridge 16,000
F-565/525 Toner cartridge 14,000 1
Drum charge wire and LED print
head
1
Note: “” means to clean the mechanism when a paper take-up or transport failure or print quality
problems occurs.
