3-82
Unique Switch 010 — Transmission
Switch
Initial
Setting
Adjust Usage/Comments
7 1 Factory use only
6 0 Factory use only
5 1 Factory use only
4 0 Factory use only
3 1 Including TTI inside the
document
0: No
1: Yes
Setting this bit to “0” transmit the document length
added with the TTI. Setting it to “1” transmit the
length including TTI inside the document. However
in this case, the image at the top of the document
might be overlapped with TTI.
(TTI length: 4.2mm)
2 0 Factory use only
1 1 The number of times PPR is detected during ECM transmission
1 time 2 times 3 times 4 times
0 1 0 0 1 1
0 1 0 1
Unique Switch 011 ~ 014 — Factory use only
