Muratec F-525 User Manual

3-8
Machine Parameter 015
Switch
Initial
Setting
Adjust Usage/Comments
7 1 FBS scanner registration
adjustment (Horizontal)
Adjusts the start point to
scan the document.
The plus setting increases
the left margin and the minus
setting decreases it.
1 step = 2 / 600 dpi
(0.0847 mm)
Note: These values
are factory set and should
not be adjusted unless
instructed by a Muratec
technical representative.
Switch 76543210 Settings
127 steps 01111111 +10.76 mm
:
00100000 +2.71 mm
:
00010000 +1.36 mm
:
00001000 +0.68mm
:
00000000 0 mm
:
10000010 -0.17 mm  Initial setting
:
10001000 -0.68 mm
:
10010000 -1.36 mm
:
10100000 -2.71 mm
:
-127steps 11111111 -10.76 mm
6 0
5 0
4 0
3 0
2 0
1 1
0 0
Machine Parameter 016
Switch
Initial
Setting
Adjust Usage/Comments
7 0 Adjustment of the scanning
stretching and squeezing for
FBS.
(Horizontal)
The plus setting stretches
the image data and the
minus setting squeezes it.
Each setting changes by
0.1%
Switch 76543210 Settings
00001111 +1.5 %
:
00001000 +0.8 %
:
00000100 +0.4 %
:
00000010 +0.2 %
00000001 +0.1 %
00000000 0 %  Initial setting
10000001 -0.1 %
10000010 -0.2 %
:
10000100 -0.4 %
:
10001000 -0.8 %
:
10001111 -1.5 %
6 0
5 0
4 0
3 0
2 0
1 0
0 0
